SEGN0820V-005
SEGN0820V-005L
Cordless Gas Insulation Nailer



● More efficiency and labor-saving than Powder Actuated Tool
● Cordless, great self-powered and easy to maneuver
● Unique design for fuel cell loading and unloading
● No gas smell when loading and unloading fuel cell
● Easy maintenance and equipped with maintenance indicator light

Fuel Cell
● Wide workable temperature range with only 12 bars pressure required.
● Fuel Cell capacity:
   App. 1100 nails (for 165 mm Fuel Cell)
   App. 1000 nails (for 154 mm Fuel Cell)
● Well designed and applicable for tools of different brands
● Working Temperature from: -15°C

SEGN0820V-005
SEGN0820V-005L
Cordless Gas Insulation Nailer


Dimension
SEGN0820V-005
● 414 x 450 x 110 mm
● 3.11 kg / 6.8 lb
(include battery + fuel cell)

SEGN0820V-005L
● 490 x 450 x 110 mm
● 3.16 kg / 6.97 lb
(include battery + fuel cell)

Contents
● 1PC     DC 8.2V Charger
● 2PCS   6V NiMH Battery
● 1PC     Safety Goggles
● 1PC     Hex Wrench
● 1PC     Blow Molded Case

Specification
Fuel cell	Both 165 & 154mm are workable
Battery	App. 4000 nails per charge

Model No.	SEGN0820V-005	SEGN0820V-005L
Nail Shank Dia	2.6~3.1 mm	3.2~3.6 mm
Concrete Nail Length	45~50 mm	42 & 52 mm
Over All Length	30~160 mm	30~200 mm

SEGN0820V-005
SEGN0820V-005L
Cordless Gas Insulation Nailer

SEGN0820V-005
SEGN0820V-005L
Cordless Gas Insulation Nailer

● To fix insulation materials onto wall
