Torque Reaction Arm w/ Housing Spring Balancer w/o Screwdriver
STD-750R-AE Pneumatic & Electric
Torque Reaction Arm
w/ Housing Spring Balancer
w/o Screwdriver
● Applicable Screwdriver Weight: 1.65/ 1.45 kg (3.64/ 3.2 lb)
● Vertical Stroke: 445/533mm (17.52"/ 20.98" )
● Max. Torque: 250kgf-cm (24.5 Nm)
● Overall Height: 936/ 927mm (36.85"/ 36.50")
● Screwdriver Grip Radius: 25-45mm
STD-750R-AE Pneumatic & Electric
Torque Reaction Arm
w/ Housing Spring Balancer
w/o Screwdriver
|
Model No. |
Pneumatic |
Electric |
Max. Working Area |
Vertical Stroke |
Screwdriver Weight |
Overall Height |
Packing |
|||
|
氣動 |
電動 |
最大工作半徑 |
垂直行程 |
適用起子重量 |
總高 |
包裝 |
||||
|
- |
- |
mm |
Inch |
mm |
lb |
kg |
Inch |
mm |
- |
|
|
STD-750R-A |
◎ |
X |
700 |
17.52 |
445 |
< 3.64 |
< 1.65 |
36.85 |
936 |
100x31x15 cm, G.W: 12kg |
|
STD-750R-AE |
◎ |
◎ |
100-714 |
20.98 |
533 |
< 3.20 |
< 1.45 |
36.50 |
927 |
100x31x15 cm, G.W: 12kg |
